Features

• Excellent performance, specially designed for 1/10 -1/12 STOCK racing. Designed to pair with HOBBYWING XR10 Stock Spec G2 ESC
• The innovative outer diameter structure of fully exposed stator core maximizes the heat dissipation area and the rear end of the motor is a big opening structure to further improve the heat dissipation effect.
• Dual sensor interface design to meet various wiring/layout requirements.
• The special copper bar is customized and the spacing of copper bar is widened, which greatly facilitates the operation of soldering wire.
• The built-in high precision Hall sensor combined with the high precision and balanced rotor guarantee outstanding linearity of the motor.
• The use of high-performance stator core, 220°C high-temperature-resistant enameled wire, high precision and high strength bearings, and copper solder tabs with super current endurance guarantees outstanding.

Applications

• 1/10th & 1/12th STOCK Class Racing

Product Specifications

• Scale - 1/10th
• Brushed/Brushless - BL
• Sensored/Sensorless - SD
• Pole Count - 2

Relevant Parameters

• LiPo Cells - 1-3S

Size & Weight

• O.D.(mm) - 35.8
• Length (mm) - 51.3
• Shaft Diameter (mm) - 3.175
• Weight (g) - 152
• Front Bearing - D9*D4*t4
• Rear Bearing - D8*D3*t4
