Case Material: Plastic
Case Size: 186*103*209mm
Weight: 1610g

Display

Display Type: 2x16 LCD
Display Backlight: Blue

Power

DC Input Voltage: 11-18V
AC Input Voltage: 100-240V 50/60HZ
Charge Wattage: 100W X 4
Discharge Wattage: 10W

Battery

Battery Types/Cells:
LiPo/LiHV/LiFe/LiIon: 1-6S
NiMH/NiCd: 1-15S
Pb: 2-20V


Battery Capacity Range:
NiMH/NiCd:100-50000mAh
LiPo/LiIon/LiFe/LiHV:100-50000mAh
Pb: 100-50000mAh

Charge and Discharge

Charge Voltage

NiMH/NiCd: Delta peak detection

LiPo: 4.18-4.25V/S
LiFe: 3.58-3.7V/S
Pb: 1.8-2.0V/S

LiIon: 4.08-4.2V/S
LiHV: 4.25-4.35V/S



Discharge Cut-off Voltage

NiMH/NiCd: 0.1-1.1V/S

LiPo:3.0-3.3V/S
LiFe:2.6-2.9V/S

LiIon: 2.9-3.2V/S
LiHV: 3.1-3.4V/S



Charge Voltage Range: 0.1-26.1V/cell
Charge Current: 0.1A-12.0A
Discharge Current: 0.1A-2.0A
Balance Current: 500mA Max.
Safety Timer: 1~720min & OFF(default: 120mins)

Working and Storage

Operating temperature: 0℃-40℃
Working humidity: 0%-75%
Storage temperature: -10℃-70℃
Storage humidity: 0%-75%

Not include extra charge lead.

(SK-100189)

SKU SK-100189
Brand SKYRC
